《智能体设计模式》之路由模式：智能决策与动态分发[译]

pip install langchain langgraph google-cloud-aiplatform langchain-google-genai google-adk deprecated pydantic

# Copyright (c) 2025 Marco Fago
#
# This code is licensed under the MIT License.
# See the LICENSE file in the repository for the full license text.

from langchain_google_genai import ChatGoogleGenerativeAI
from langchain_core.prompts import ChatPromptTemplate
from langchain_core.output_parsers import StrOutputParser
from langchain_core.runnables import RunnablePassthrough, RunnableBranch

# --- Configuration ---
# Ensure your API key environment variable is set (e.g., GOOGLE_API_KEY)
# 确保你的 API 密钥环境变量已设置 (如 GOOGLE_API_KEY)
try:
    llm = ChatGoogleGenerativeAI(model="gemini-2.5-flash", temperature=0)
    print(f"Language model initialized: {llm.model}")
except Exception as e:
    print(f"Error initializing language model: {e}")
    llm = None

# --- Define Simulated Sub-Agent Handlers (equivalent to ADK sub_agents) ---
# --- 定义模拟的子智能体处理器 (等同于 ADK 中的 sub_agents) ---

def booking_handler(request: str) -> str:
    """Simulates the Booking Agent handling a request."""
    print("\n--- DELEGATING TO BOOKING HANDLER ---")
    return f"Booking Handler processed request: '{request}'. Result: Simulated booking action."

def info_handler(request: str) -> str:
    """Simulates the Info Agent handling a request."""
    print("\n--- DELEGATING TO INFO HANDLER ---")
    return f"Info Handler processed request: '{request}'. Result: Simulated information retrieval."

def unclear_handler(request: str) -> str:
    """Handles requests that couldn't be delegated."""
    print("\n--- HANDLING UNCLEAR REQUEST ---")
    return f"Coordinator could not delegate request: '{request}'. Please clarify."

# --- Define Coordinator Router Chain (equivalent to ADK coordinator's instruction) ---
# This chain decides which handler to delegate to.
# --- 定义协调员的路由链 (等同于 ADK 协调员的指令) ---
# 这个链负责决定将任务委派给哪个处理器。
coordinator_router_prompt = ChatPromptTemplate.from_messages([
    ("system", """Analyze the user's request and determine which specialist handler should process it.
     - If the request is related to booking flights or hotels, output 'booker'.
     - For all other general information questions, output 'info'.
     - If the request is unclear or doesn't fit either category, output 'unclear'.
     ONLY output one word: 'booker', 'info', or 'unclear'."""),
    ("user", "{request}")
])

if llm:
    coordinator_router_chain = coordinator_router_prompt | llm | StrOutputParser()

# --- Define the Delegation Logic (equivalent to ADK's Auto-Flow based on sub_agents) ---
# Use RunnableBranch to route based on the router chain's output.
# --- 定义委派逻辑 (等同于 ADK 基于 sub_agents 的自动流) ---
# 使用 RunnableBranch 根据路由链的输出进行路由。

# Define the branches for the RunnableBranch
# 为 RunnableBranch 定义分支
branches = {
    "booker": RunnablePassthrough.assign(output=lambda x: booking_handler(x['request']['request'])),
    "info": RunnablePassthrough.assign(output=lambda x: info_handler(x['request']['request'])),
    "unclear": RunnablePassthrough.assign(output=lambda x: unclear_handler(x['request']['request'])),
}

# Create the RunnableBranch. It takes the output of the router chain
# and routes the original input ('request') to the corresponding handler.
# 创建 RunnableBranch。它会接收路由链的输出，
# 并将原始输入 ('request') 路由到相应的处理器。
delegation_branch = RunnableBranch(
    (lambda x: x['decision'].strip() == 'booker', branches["booker"]), # Added .strip()
    (lambda x: x['decision'].strip() == 'info', branches["info"]),     # Added .strip()
    branches["unclear"] # Default branch for 'unclear' or any other output
)

# Combine the router chain and the delegation branch into a single runnable
# The router chain's output ('decision') is passed along with the original input ('request')
# to the delegation_branch.
# 将路由链和委派分支组合成一个可执行单元
# 路由链的输出 ('decision') 会连同原始输入 ('request') 一起
# 传递给 delegation_branch。
coordinator_agent = {
    "decision": coordinator_router_chain,
    "request": RunnablePassthrough()
} | delegation_branch | (lambda x: x['output']) # Extract the final output

# --- Example Usage ---
# --- 使用示例 ---
def main():
    if not llm:
        print("\nSkipping execution due to LLM initialization failure.")
        return

    print("--- Running with a booking request ---")
    request_a = "Book me a flight to London."
    result_a = coordinator_agent.invoke({"request": request_a})
    print(f"Final Result A: {result_a}")

    print("\n--- Running with an info request ---")
    request_b = "What is the capital of Italy?"
    result_b = coordinator_agent.invoke({"request": request_b})
    print(f"Final Result B: {result_b}")

    print("\n--- Running with an unclear request ---")
    request_c = "Tell me about quantum physics."
    result_c = coordinator_agent.invoke({"request": request_c})
    print(f"Final Result C: {result_c}")

if __name__ == "__main__":
    main()

Language model initialized: models/gemini-2.5-flash
--- Running with a booking request ---

--- DELEGATING TO BOOKING HANDLER ---
Final Result A: Booking Handler processed request: 'Book me a flight to London.'. Result: Simulated booking action.

--- Running with an info request ---

--- DELEGATING TO INFO HANDLER ---
Final Result B: Info Handler processed request: 'What is the capital of Italy?'. Result: Simulated information retrieval.

--- Running with an unclear request ---

--- DELEGATING TO INFO HANDLER ---
Final Result C: Info Handler processed request: 'Tell me about quantum physics.'. Result: Simulated information retrieval.

# Copyright (c) 2025 Marco Fago
#
# This code is licensed under the MIT License.
# See the LICENSE file in the repository for the full license text.

import uuid
from typing import Dict, Any, Optional

from google.adk.agents import Agent
from google.adk.runners import InMemoryRunner
from google.adk.tools import FunctionTool
from google.genai import types
from google.adk.events import Event

# Colab 代码链接：https://colab.research.google.com/drive/10wxRlPyDJ70pPEtWWA3Aa3tjvfobrB3m

# 安装依赖
# pip install google-genai google-adk

# --- Define Tool Functions ---
# These functions simulate the actions of the specialist agents.
# --- 定义工具函数 ---
# 这些函数模拟了专业智能体的具体行动。

def booking_handler(request: str) -> str:
    """
    Handles booking requests for flights and hotels.
    Args:
        request: The user's request for a booking.
    Returns:
        A confirmation message that the booking was handled.
    """
    print("-------------------------- Booking Handler Called ----------------------------")
    return f"Booking action for '{request}' has been simulated."

def info_handler(request: str) -> str:
    """
    Handles general information requests.
    Args:
        request: The user's question.
    Returns:
        A message indicating the information request was handled.
    """
    print("-------------------------- Info Handler Called ----------------------------")
    return f"Information request for '{request}'. Result: Simulated information retrieval."

def unclear_handler(request: str) -> str:
    """Handles requests that couldn't be delegated."""
    return f"Coordinator could not delegate request: '{request}'. Please clarify."

# --- Create Tools from Functions ---
# --- 从函数创建工具 ---
booking_tool = FunctionTool(booking_handler)
info_tool = FunctionTool(info_handler)

# Define specialized sub-agents equipped with their respective tools
# --- 定义配备了各自工具的专业子智能体 ---
booking_agent = Agent(
    name="Booker",
    model="gemini-2.0-flash",
    description="A specialized agent that handles all flight and hotel booking requests by calling the booking tool.",
    tools=[booking_tool]
)

info_agent = Agent(
    name="Info",
    model="gemini-2.0-flash",
    description="A specialized agent that provides general information and answers user questions by calling the info tool.",
    tools=[info_tool]
)

# Define the parent agent with explicit delegation instructions
# --- 定义带有明确委派指令的父智能体 ---
coordinator = Agent(
    name="Coordinator",
    model="gemini-2.0-flash",
    instruction=(
        "You are the main coordinator. Your only task is to analyze incoming user requests "
        "and delegate them to the appropriate specialist agent. Do not try to answer the user directly.\n"
        "- For any requests related to booking flights or hotels, delegate to the 'Booker' agent.\n"
        "- For all other general information questions, delegate to the 'Info' agent."
    ),
    description="A coordinator that routes user requests to the correct specialist agent.",
    # The presence of sub_agents enables LLM-driven delegation (Auto-Flow) by default.
    # 定义了 sub_agents 默认就会启用由大语言模型驱动的委派。
    sub_agents=[booking_agent, info_agent]
)

# --- Execution Logic ---
# --- 执行逻辑 ---
def run_coordinator(runner: InMemoryRunner, request: str):
    """Runs the coordinator agent with a given request and delegates."""
    """用给定的请求运行协调员智能体并进行委派。"""
    print(f"\n--- Running Coordinator with request: '{request}' ---")
    final_result = ""
    try:
        user_id = "user_123"
        session_id = str(uuid.uuid4())
        runner.session_service.create_session(
            app_name=runner.app_name, user_id=user_id, session_id=session_id
        )

        for event in runner.run(
            user_id=user_id,
            session_id=session_id,
            new_message=types.Content(
                role='user',
                parts=[types.Part(text=request)]
            ),
        ):
            if event.is_final_response() and event.content:
                # Try to get text directly from event.content to avoid iterating parts
                if hasattr(event.content, 'text') and event.content.text:
                     final_result = event.content.text
                elif event.content.parts:
                    # Fallback: Iterate through parts and extract text (might trigger warning)
                    text_parts = [part.text for part in event.content.parts if part.text]
                    final_result = "".join(text_parts)
                # Assuming the loop should break after the final response
                break

        print(f"Coordinator Final Response: {final_result}")
        return final_result
    except Exception as e:
        print(f"An error occurred while processing your request: {e}")
        return f"An error occurred while processing your request: {e}"

def main():
    """Main function to run the ADK example."""
    """运行 ADK 示例的主函数。"""
    print("--- Google ADK Routing Example (ADK Auto-Flow Style) ---")
    print("Note: This requires Google ADK installed and authenticated.")

    runner = InMemoryRunner(coordinator)
    # Example Usage
    # 使用示例
    result_a = run_coordinator(runner, "Book me a hotel in Paris.")
    print(f"Final Output A: {result_a}")
    result_b = run_coordinator(runner, "What is the highest mountain in the world?")
    print(f"Final Output B: {result_b}")
    result_c = run_coordinator(runner, "Tell me a random fact.") # Should go to Info
    print(f"Final Output C: {result_c}")
    result_d = run_coordinator(runner, "Find flights to Tokyo next month.") # Should go to Booker
    print(f"Final Output D: {result_d}")


if __name__ == "__main__":
    main()
